(2013) 1000 US ton UBE Used UZ1000 Injection Molding Machine

Description

GMB#5877

(2013) 1000 US ton UBE Used UZ1000 Injection Molding Machine

Brand: UBE

Year: 2013

Model: UZ1000

Voltage 460V

Shot Size 148 oz

Clamping Force 1000 US ton

Tie Bar Spacing 60" x 50"

Injection capacity: 277.96 cu cm

Injection pressure: 24.860 psi

Screw diameter: 100mm

Clamp style: toggle

Platen size: 76.92" x 66.92"

Clamp stroke: 55.11

Min mold height: 52.75

Max mold height: 19.69

Equipped with: hydraulic knock outs; four(4) circuits core pull; two(2) circuits air blow; SPI robot interface; servo clamp control; six(6) pneumatic valve gates

Clamp equipped with servo valve control system.

Injection end: New Hagglund high speed hydraulic screw motor

Injection Capacity: Machine equipped with A size barrel.  Machine can be up sized to B size, 4.41 in, 185 oz capacity

Dimensions:  506" L x 143"W x 111"H

Weight:  114,000 lbs

Location: USA

Price Exworks as is / where is

Product Notice

Listing information contained herein is provided solely by seller. Garesco makes every effort to verify the accuracy of information; however listings are subjective to information obtained by seller and are not warranted by Garesco. Items provided as-is unless otherwise stated or negotiated.

Please note that this description may have been translated automatically. Contact us for further information.
