(2016) Sodick OPM250L 2016 3D Printer

Description

GMB#45133

(2016) Sodick OPM250L 2016 3D Printer

Brand: Sodick

Model: OPM250L

Year: 2016

Max Spindle Speed: 45,000 RPM

X-Axis Travel: 10.24" (260 mm)

Y-Axis Travel: 10.24" (260 mm)

Z-Axis Travel: 10.24" (260 mm)

Spindle Z-Axis Stroke: 3.94" (100 mm)

Tool Holder Type: HSK-E25 (Dual face contact)

Max Workpiece / Build Size: 9.84" x 9.84" x 9.84"(250mm x 250mm x 250 mm)

Molding Tank Inner Dimensions: 11.42" x 11.42"(290mm x 290 mm)

Max Workpiece Weight: 220 lbs (100 kg)

Laser Type: Yb (Ytterbium) Fiber Laser

Max Laser Output: 500 W

Laser Wavelength: 1070 nm

Laser Scanning Method: Galvano Method

Power On Time: 20779 Hrs

Cut Time: 1244 Hrs

Laser Time: 3173 Hrs

Spindle Time: 1712 Hrs

Overall Machine Dimensions: 73.62" x 87.80" x 80.91" (1,870mm x 2,230mm x 2,055 mm)

Machine Weight: 9,920 lbs (4,500 kg)

Equipped with:

Sodick LN2RP CNC Control

Sodick OS-FLASH CAM Software

Automatic Tool Changer (ATC): 16 Position Automatic Tool Changer

Tool Measurement: Blum Laser Tool Length Measuring System

Drive System: Rigid Linear Motors (X- Y- Z axes)

Absolute Linear Glass Scales (X/Y/Z)

High Speed Spindle Chiller Unit

Automatic Material Recovery System (MRS): Integrated unit for powder supply. collection. and automatic sieving for material recycling with dedicated Sinter software

Fume Collector

Nitrogen Supply Interface

Conformal Cooling Capability

To produce complex, high-hardness steel molds in a single setup. Ideal for creating conformal cooling channels that reduce injection molding cycle times by up to 60%, it is widely used for precision tooling, mold & die production, and advanced components in aerospace and medical industries

Location: USA

Price exworks as is / where is
